Sanitary standard premade pouch packaging machine for powders

FOB Reference Price:Get Latest Price
US $27,000-30,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Other
Condition:
New
Application:
Chemical, Commodity, Food, Medical
Packaging Type:
Bags, Capsule, Film, Pouch, Stand-up Pouch
Packaging Material:
Paper, Plastic
Automatic Grade:
Automatic
Driven Type:
Electric
Voltage:
220V
Power:
8KW
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
Jinchi Machinery
Model Number:
JCK-720
Weight:
2700kg
Dimension(L*W*H):
4076*4045*4300mm
Certification:
CE Certificate
After-sales Service Provided:
Engineers available to service machinery overseas
After-sales Service:
Full life
Packing speed:
10-50bags/min
Training:
Provide by technician in commissioning service
Material:
Stainless Steel 304
Name:
Sanitary standard premade pouch packaging machine for powders
Supply Ability
Supply Ability:
30 Set/Sets per Month
Packaging & Delivery
Packaging Details
Fumigation wooden cases, which are well sealed and strong enough for long term trip, and suitable for multi-times loading & unloading by forklift.
Port
Shanghai
Lead Time :
20-45 days after deposit

Contact Details



Sanitary standard premade pouch packaging machine for powders

Samples

Certificate

1

Features

1.A wide range of packaging, Suit for packing various powder of different state, nature.Suit for different types bags.

2.Easy operate, adopt PLC control, man-machine operate system, intuitive and convenient operation.

3.It takes about 10 minutes to change the filling material, convenient and quick.

4.High degree of automation. Unmanned in the whole process of the weighing and packaging. Automatic

alarm if any machine failures.

5.Perfect prevention system, intelligent detection whether the bag is open, whether open completes. Don’t

feeding, sealing when the bag is closed, don’t waste the bags and filling materials. Saving the cost.

6.The packaging parts of the machine are made of stainless steel to ensure the hygiene and safety of the

filling material, up to the GMP standard.

7.Use imported plastic bearings on the important components, without refueling, to reduce the pollution of

filling materials;



Technical Parameters

 Name

 Pre-made pouch powder packing machine

 Model

JC-L

 Measurement

 Screw weigher,Liner weigher

 Operate interface

 Touch screen

 Bag type

Stand-up bag,Zipper bag,Four side seal bag,Three side seal bag,Paper bag,Reticule,M type bag etc.

 Bag specification

 W:160~300mm L:100~400mm(Coding requirement length: Min140mm)

 Work flow

 1.Pouch supply 2.Date print 3.Open the bag 4.Feeding 5.Heat seal 6.Output

 Filling range

 5~2500g

 Packing speed

 10~40bags/min

 Packing accuracy

 The tolerance is≤±1%

 Weight

 2000kg

 Dimension(L*W*H)

 1645mm*1645mm*1640mm

Main Equipment

1 (3)

Packing & Shipping

_



Commissioning & After-sales Service

We make accurate factory layout design according to customer’s factory size; if the customer needed, we could make workshop design with electric power, water supply, gas power, material storage, final storages, workers’ restroom, etc.

If customer need, we will send engineer for the commissioning service. 1-2 of our engineer will

go to your factory to install and adjust the processing line to realize normal production at shortest time.
Our engineers have responsibility to train and teach the workers how to operate, clean, maintain the repair all the machine, until the worker could well operate the production line.

It normally costs 10 days for the commissioning service, and we supply 1 year guarantee from the date of completion of commissioning service.
The engineer’s round-trip flight tickets, accommodation and daily salary USD100 are on client’s account.





Company Information

factory--Jinchi





FAQ

Q: Can your machine be customized ?

A: Yes, we are a professional manufacturer specilized in packaging machine for more than 10 years and we have a strong design&technical team. We can design and manufacture as per your requirements.



Q: How to get an accurate quotation ?

A: Please provide us the detail of the workpiece such as drawing and dimensions.



Q: what’s the package ?

A: All goods are packed in wooden box.



Q: Do you offer Installation&debugging?

A: Our engineers are available to service machinery overseas to help customers to solve machine problems.



Q: what’s policy for guarantee and broken parts ?

A: As for machine products, our company provides 12 months for all mechanical parts with the exception of electrical and electronic parts and those subjects to normal wear and tear. The guarantee is intended limited to the replacement of the broken part after checking the construction fault. The inspection of the causes of the trouble or the breakdown of the parts is exclusively up to the manufacturing company. All in all, our company can offer you assured products.
